Your Trusted Strategic Partner Since 2016

Founded in 2016, EIE has quickly established itself as a reliable partner in electronics engineering, PCB design, and manufacturing. With a strong focus on innovation and precision, we offer a comprehensive suite of services, ranging from concept design and prototyping to full-scale production, assembly, and testing. Our fully equipped design and manufacturing labs, located in Pakistan, support our global operations, enabling us to deliver customized, high-quality solutions to meet the unique needs of both local and international clients.

Learn more


From Ideas to Aftermarket and Everything in Between


Design and Engineering


OEM / ODM / PCBA Services


Logistics and Fulfillment


After Sale Services


Supply Chain Services


Testing and Verification Services

Transforming Ideas into Reality with Expert Engineering

Local Customer Service

We have advanced labs and manufacturing facilities located in Pakistan, enabling us to provide prompt pre-sales and after-sales service and comprehensive technical support.

Non-Disclosure Agreement

We adhere to strict confidentiality agreements (NDAs) to safeguard our customers' interests, fostering long-term partnerships with numerous esteemed clients.

Rapid Delivery

Two shifts in production department provide you faster delivery time. Quick-turn PCB prototypes can be delivered in 24 hours, PCBA prototypes within 2-3 days.

Quality Control and Assurance

Our commitment is to never compromise on the safety, compliance and quality of our products and services.


Our Clients

Enertia PAF Zong EZGyser TFPipes Agros Kythertek Smart PCBS
Enertia PAF Zong EZGyser TFPipes Agros Kythertek Smart PCBS

Who We Serve


We serve customers in demanding markets where reliability matters.

Automobile Industry

Consumer Electronics

Telecom Industry

Agritech

Transportation and Logistics

Smart Home Technology

Renewable Energy

Robotics

Electronic Manufacturing Service

Home Appliances

Educational Institutes

Security Systems


How We Work

Turn complex into simple with out three simple steps.

1️⃣Project Consultation

​Tell us about your PCB requirements including PCB file, BOM list and volume details.​

2️⃣Assembly and Production

​Once the prototype is approved, we move to full-scale assembly and production, with constant quality monitoring.

3️⃣Testing and Delivery

​After final testing, we ship your fully assembled PCBs on time and with the highest quality standards.

Get Your Quote Now

Fill in the fields below and we will get back to you with your quotation.

Add details about your project here.

Thank you for your feedback!

Our team will message you back as soon as possible.

In the meantime we invite you to visit our website.


EIE - Innovating PCBA & Manufacturing with Custom Designs, Engineering, Prototyping & Reliable Support

Looking for answers? Check out our FAQ for everything you need to know!

EIE provides a comprehensive suite of services, including design and engineering, PCB design and assembly, PCBA services, electronic ​repair services, reverse engineering, green energy solutions, marketing support, CRM support, logistics and fulfillment, after-sales services,​supply chain services, and test services.

We are your strategic partner throughout the entire process, from concept design and prototyping to full-scale production, assembly, and ​testing, ensuring high-quality and customized solutions tailored to your needs.

We cater to a wide range of industries, including automotive, consumer electronics, telecommunications, renewable energy, ​transportation and logistics, agriculture, smart home technology, robotics, security systems, electronics manufacturing services, home appliances, and the education sector.

It depends on your demand on PCB types, number of the board layers, PCB assembly services, testing and shipping requirements.

​Yes, we offer high quality one-stop service including PCB prototype & PCBA Manufacturing. We have a strict internal quality control process and test methods from raw material to PCB assembly during PCB assembly manufacturing process, making sure our customers can always get high-quality products. Get a quick quote for any type of your requirements.

PCB assembly is that the PCB manufacturer takes charge the whole PCB assembly manufacturing including electronic components purchasing, manufacturing and assembly.

① Save time and money

Delegating the whole PCB assembly manufacturing projects to a turnkey PCB assembly manufacturer enables greatly save your time. In other aspect, it is beneficial to save money if we choose one-stop PCB assembly manufacturing services because we don’t need to spend time to select other services like PCB assembly testing service provider.

② Spot error in time

Adopting one-stop PCB assembly manufacturing services can effectively detect and solve the errors timely. The engineer can help make some modification on design phrase start from your customized or ordinary orders. If we cope with the errors after the whole production is completed, it will cause great cost.

③ Better monitor the process of PCB assembly manufacturing projects

Because we decide to deliver the whole PCB assembly manufacturing projects to one supplier, we don’t need to spend time to communicate with other suppliers. Once you want to make some modification or you detect some errors, you can discuss with the engineer in time, which minimizes the loss greatly.

④ Other services

Sometime, a turnkey PCB assembly manufacturing supplier also provide other services, for example the inventory and shipping arrangements. It enables greatly save your energy and money and improve your competition edge.

PCB assembly manufacturing includes many aspects. Here take a 4 layer PCB as example.


① PCB layout


Checking the PCB layout design in advance. Generally, PCB assembly manufacturing supplier would accept the demand from the customer. In this step, PCB layout design will be detected to check whether it meets the manufacturing standard and any detects may appear.


② Inner PCB layer


A layer of photosensitive film will be covered after the copper clad laminate is cleaned. This kind of film gets cure under exposing on the light, and forms a protective film on the copper foil of the CCL.


③ Drilling the core board and inspection


After the core board is completely fabricated, then we need to punch alignment holes on it for better aligning with other materials.


Once the core board is pressed with other PCB layers, it is difficult to make some modification. Thus, the inspection becomes an important part, which compare with the PCB layout design drawings through machines.


④ Lamination


Prepare uses to adhere the core board and the outer cooper foil which has insulation capabilities. Fixed the copper foil of the lower layer and two layers of prepare with the alignment hole and the iron plate of the lower layer in advance, then placed the prepared core board in the alignment hole.


⑤ Drilling


Drill holes from the top and bottom, then make the hole wall become metallizing to get conduct electricity, you can connect 4 layers copper foils together.


Locating the inner core board through X-ray drilling machine, and then making position holes on the PCB to make sure that the following drilling passes through from the center hole.


⑥ Copper chemical precipitation of the hole wall


The through hole on the PCB is for connecting different layers. In general, a 25 microns of copper film is reasonable to get connecting with other layers. This thickness needs to be electroplated.


⑦ Outer PCB layer


Make full use of photocopied film and photosensitive film to transfer the outer PCB layer to copper foil. Unlike the inner PCB layer, it adopts positive film. The photosensitive film on the PCB is cured to cover those non-circuit areas.


⑧ Outer PCB layer etching


Remove the cured photosensitive film on the PCB, then use the strong base to clean those unnecessary and covered copper foil. For those tin coating left on the copper foil should be remove through tin solution.

Selection suitable PCB assembly manufacturing technology directly impacts the manufacturing efficiency, and product quality. Two technologies are commonly used in PCB assembly manufacturing: surface mount technology and through hole technology.


Surface Mount Technology


Like some electronic products such as medical machines and smartphones, their PCB assembly manufacturing process adopt surface mount technology.


Compared with through hole technology, it allows you to process the PCB in mass with high automation efficiency.

​We offer rapid delivery, with quick-turn PCB prototypes available within 24 hours and PCBA prototypes within 2-3 days.

Yes, we adhere to strict confidentiality agreements (NDAs) to safeguard our customers' interests and foster long-term partnerships.

​We offer comprehensive after-sales services, including customer support and technical assistance, to ensure satisfaction with our products and services.

​Absolutely! Our marketing support includes strategy development and campaign management, while our CRM support focuses on optimizing client interactions and enhancing customer satisfaction.

We specialize in providing renewable energy systems for various applications, including domestic, industrial, irrigation, and remote locations, with tailored power management and backup solutions.

​Our logistics and fulfillment services encompass inventory management, order processing, shipping, and handling, ensuring timely and efficient delivery of products to our clients.
